Plastic-coated straight towel radiator
Model : YE1200×500
Material : Low carbon steel
Guarantee : 5 years
Horizontal tube : Φ22
Vertical tube : 30×40mm
|
  EN442 ROHS |
|
Model |
Length/A(MM) |
Width/B(MM) |
Height/D(MM) |
Center Distance/C(MM) |
Power(W) |
|
YE600*400 |
600 |
400 |
30 |
350 |
340 |
|
YE600*450 |
600 |
450 |
30 |
400 |
370 |
|
YE600*500 |
600 |
500 |
30 |
450 |
400 |
|
YE600*550 |
600 |
550 |
30 |
500 |
440 |
|
YE600*600 |
600 |
600 |
30 |
550 |
480 |
|
YE800*400 |
800 |
400 |
30 |
350 |
500 |
|
YE800*450 |
800 |
450 |
30`` |
400 |
560 |
|
YE800*500 |
800 |
500 |
30 |
450 |
620 |
|
YE800*550 |
800 |
550 |
30 |
500 |
680 |
|
YE800*600 |
800 |
600 |
30 |
550 |
750 |
|
YE1000*400 |
1000 |
400 |
30 |
350 |
850 |
|
YE1000*450 |
1000 |
450 |
30 |
400 |
950 |
|
YE1000*500 |
1000 |
500 |
30 |
450 |
1060 |
|
YE1000*550 |
1000 |
550 |
30 |
500 |
1170 |
|
YE1000*600 |
1000 |
600 |
30 |
550 |
1270 |
|
YE1200*400 |
1200 |
400 |
30 |
350 |
900 |
|
YE1200*450 |
1200 |
450 |
30 |
400 |
1010 |
|
YE1200*500 |
1200 |
500 |
30 |
450 |
1120 |
|
YE1200*550 |
1200 |
550 |
30 |
500 |
1230 |
|
YE1200*600 |
1200 |
600 |
30 |
550 |
1350 |
|
YE1500*400 |
1500 |
400 |
30 |
350 |
1200 |
|
YE1500*450 |
1500 |
450 |
30 |
400 |
1350 |
|
YE1500*500 |
1500 |
500 |
30 |
450 |
1500 |
|
YE1500*550 |
1500 |
550 |
30 |
500 |
1650 |
|
YE1500*600 |
1500 |
600 |
30 |
550 |
1800 |
|
YE1800*400 |
1800 |
400 |
30 |
350 |
1300 |
|
YE1800*450 |
1800 |
450 |
30 |
400 |
1460 |
|
YE1800*500 |
1800 |
500 |
30 |
450 |
1620 |
|
YE1800*550 |
1800 |
550 |
30 |
500 |
1780 |
|
YE1800*600 |
1800 |
600 |
30 |
550 |
1950 |
|
